Use Black Phenolic Resin Plate For Enterprise Workshop Workbench
Through special processing of decorative color paper, reoccupy etch steel at 150 ℃ high temperature 1430 psi high pressure environment, through melting and irreversible aging hardening of 60 minutes a integrated.
Comprehensive erosion resistance against acid and alkali, three levels of protective structure:
1. The Chemical membrane Chemical - resistant qualities.
2. The color Paper Deco Paper;
3. Special multi-layer Kraft Paper (Kraft Paper).
1. Slab Size:
1220mm*2440mm ,1220mm*3050mm ,1220mm*3660mm
1525mm*3050mm ,1525mm*3660mm
Thickness: 12.7/16/19 mm
Surface:Matte
2. Product Description
Phenolic Resin Pane color is rich, have such as bright surface of dumb light of a variety of surface texture, its surface after the special chemical treatment has more powerful chemical resistance performance.
Phenolic Resin Pane is a kind of specially made for laboratory stage face plate, by more than 140 phenolic resin impregnated finest imported kraft paper.
3. Acid resistance
| Test name |
Test result |
Grading result |
| 85% sulfuric acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 98% sulfuric acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 50% nitric acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 65% nitric acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 36% hydrochloric acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 85% phosphoric acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 40% hydrofluoric acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 60% chromic acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| 99% glacial acetic acid |
Specimen surface gloss and color no obvious change |
Level 1 |
| Acetic acid |
Specimen surface gloss and color no obvious change |
Level 1 |
4.Physical Characteristics
| Mechanical Property |
Test Standard |
Test Result |
| Flexural Strength |
MD |
205Mpa |
| Compressive Strength |
MD |
321Mpa |
| Tensile Strength |
MD |
178Mpa |
| IZOD Impact strength |
CD |
102Mpa |
| ASTM D 256-06a |
42J/M |
| Flexural Modules |
ASTM D 792-07 |
16.5Gpz |
| Rockwell Hardness |
ASTM D 785-08 |
HRE79.7 |
| Liquid Absorption |
ASTM D 570-98 |
0.73% |
